MRCOOL® E Star DIY 4th Gen 36k BTU 208-230V/60Hz Ductless Mini-Split Heat Pump Complete System

MRCOOL® E Star DIY 4th Gen 36k BTU 208-230V/60Hz Ductless Mini-Split Heat Pump Complete System

Description

The MRCOOL® 4th Generation DIY 36K BTU, 18 SEER Ductless Heat Pump is one of the most powerful single-zone systems offered in the DIY Series. This complete system has the heating and cooling performance to cover an area up to 1500 sq. ft while still being able to achieve an 18 SEER efficiency rating. All of this performance is within a system that can be easily installed by a homeowner with a few hand tools thanks to the patented MrCool Pre-Charged Quick-Connect Line Set that makes connecting refrigerant piping as simple as turning a few wrenches. The benefits of this system are not limited to the performance and ease of installation. This system also has many operational functions and features that sets it apart. The user can select from up to six operation modes AUTO, HEAT, COOL, FAN-ONLY, DRY (dehumidification), and SLEEP. This system features a Follow Me function which can constantly adjust the temperature of the room by sensing the temperature from the location of the handheld remote controller. This system can also be operated with an Apple or Android smartphone by downloading the Smart HVAC app. MrCool offers a limited lifetime compressor warranty on this system.

• Up to 18.3 SEER2
• Gold Fin® condenser: corrosion-resistant coastal living - don't worry, our condenser is built to resist long term corrosion
• Variable-speed DC inverter compressor technology cuts operating costs
• R-410A environmentally friendly refrigerant
• Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty









Product Specifications

MRCOOL® E Star DIY 4th Gen 36k BTU 208-230V/60Hz Ductless Mini-Split Heat Pump Complete System  Product Specifications

SEER	18
SEER2	18.3
EER	8.7
EER2	8.7
COP 47	2.81
HSPF	hspf4/hspf5 : 12/9
HSPF2	hspf2-4/hspf2-5 : 8/6.4
CFM	673.53/502.94/367.65
TONNAGE	3
COOLING CAPACITY	36000 BTU
HEATING CAPACITY	36000 BTU
VOLTAGE	208-230 V
PHASE	1
CYCLE	60 Hz
MAX FUSE BREAKER	35 A
MIN CIRCUIT AMPACITY	28 A
COLOR	White
COLOR FAMILY	White
RATED LOAD	0.50 A
MAX COVERAGE AREA	Up to 1500 sqft
ZONE CAPACITY	1
REFRIGERANT TYPE	R-410A
REFRIGERANT VOLUME	111.1 oz
DECIBEL RATING	52/45/34
DECIBEL RATING LOW	34 dBA
DECIBEL RATING HIGH	52 dBA
OSCILLATION	4-W
INVERTER	Yes
MIN AMBIENT COOL	5F - 122F
MIN AMBIENT HEAT	5F - 75F
LINE SET LENGTH	25ft
MAX LINESET LENGTH	75 ft
LIQUID LINE SIZE	3/8 in
SUCTION LINE SIZE	5/8 in
COMPRESSOR MOTOR TYPE	Rotary
CONDENSER FAN MOTOR RPM	950/250
BLOWER MOTOR RPM	1200/950/750
AUXILIARY HEATER INCLUDED	No
AUXILIARY HEATER AVAILABLE	No
FAN ONLY OPTION	Yes
QUIET MODE	Yes
AUTO COOL	Yes
WIFI COMPATIBILITY	Yes
APP COMPATIBILITY	Yes
WORKS WITH IOS	Yes
WORKS WITH ANDROID	Yes
REMOTE CONTROL INCLUDED	Yes
UL LISTED	Yes
ENERGY STAR CERTIFIED	No
AHRI CERTIFIED	Yes
REGISTERED WARRANTY	Limited Lifetime Compressor
BASE WARRANTY	5-year Parts/7-year Compressor
BASE PARTS WARRANTY	5-year Parts
REGISTERED COMPRESSOR WARRANTY	Limited Lifetime Compressor
BASE COMPRESSOR WARRANTY	7-year Compressor
HAS BATTERIES	Yes
CONTAINS ELECTRONICS	Yes
CONTAINS CHEMICALS	Yes
CONTAINS AEROSOL	Yes
CONTAINS COMPRESSED GAS	Yes
PROPOSITION 65 WARNING	Yes
RESTRICTED STATES	GU;PR;VI
CONDENSER DEPTH	16.14 in
CONDENSER HEIGHT	31.89 in
CONDENSER WIDTH	37.24 in
CONDENSER WEIGHT	147.27 lbs
AIR HANDLER DEPTH	11.10 in
AIR HANDLER HEIGHT	14.25 in
AIR HANDLER WIDTH	49.57 in
AIR HANDLER WEIGHT	47.84 lbs
