MRCOOL Hyper Heat 2nd Gen 36K BTU, 3 Ton, 17.4 SEER2 Central Ducted Condenser (CENTRAL-36-HP-C-230B00-O)

MRCOOL Hyper Heat 2nd Gen 36K BTU, 3 Ton, 17.4 SEER2 Central Ducted Condenser (CENTRAL-36-HP-C-230B00-O)

Description

This product only includes a condenser.

The 36K MRCOOL® Hyper Heat Central Ducted Condenser is specifically designed to deliver exceptional performance in extreme weather conditions, from freezing winters to sweltering summers. This high-performance system is engineered for efficiency, integrating DC Inverter and variable speed technology for reliable operation. With a SEER2 rating of up to 17.4 and an HSPF2-4 rating of up to 10.2, it effectively balances powerful heating and cooling while optimizing energy use. The system comes with the MRCOOL® Smart thermostat, allowing you to control your indoor climate easily.

The 36K MRCOOL® Hyper Heat Central Ducted Condenser and the 36K MRCOOL® VersaPro® Central Ducted Air Handler are designed to work together seamlessly. The air handler is versatile, accommodating multiple installation configurations and supports an optional heat kit for enhanced functionality. The system uses R-454B refrigerant to reduce environmental impact, an eco-friendly choice that aligns with sustainable practices. The outdoor condenser is made with a painted galvanized steel exterior, while the air handler boasts a compact design, a slide-out blower, and a self-diagnostic panel for simplified maintenance and troubleshooting.

This system is backed by a comprehensive 10-year warranty covering the compressor, parts, and labor, providing lasting reliability and peace of mind. The labor warranty is automatically activated at the time of installation, eliminating the need for registration. Upgrade your home's heating and cooling system with the dependable and efficient 36K MRCOOL® Hyper Heat Central Ducted Condenser today!

Product Specifications

MRCOOL Hyper Heat 2nd Gen 36K BTU, 3 Ton, 17.4 SEER2 Central Ducted Condenser (CENTRAL-36-HP-C-230B00-O) Product Specifications

Dimensions	16.34" D x 38.39" H x 38.58" W
SEER2	17.4
EER2	11.7
HSPF-4	10.2
HSPF-5	8.6
CFM	3001.8
Tonnage	3
Cooling Capacity (BTU)	36000
Heating Capacity (BTU)	37000
Voltage (V)	208-230
Phase	1
Cycle	60
Max Fuse Breaker (A)	30
Min Circuit Ampacity (A)	29
Color	gray
Refrigerant Type	R454B
Refrigerant Volume (OZ)	126.99
Decibel Rating (DBA)	62.5
Liquid Line Size	3/8
Suction Line Size	3/4
WIFI Compatibility	Yes
APP Compatibility	Yes
ETL Certified	Yes
Energy Star Certified	Yes
AHRI Certified	Yes
Base Parts Warranty	10 Years
Base Compressor Warranty	10 Years
Base Labor Warranty	10 Years
Contains Electronics	Yes
Contains Chemicals	Yes
Contains Compressed Gas	Yes
Net Weight (Lbs)	204.15
Gross Depth (In)	19.68
Gross Height (In)	42.52
Gross Width (In)	45.08
Gross Weight (Lbs)	253.23

Product Manual

Product Warranty

MRCOOL Limited Lifetime Warranty

LIMITATIONS OF WARRANTIES

Q1 How do I register my warranty?

Answer: Go to here to file your warranty.

Q2 How do I find the AHRI number of my unit?

Answer: You can find links to the AHRI certificates on the documentation page at mrcool.com/documentation.
