MRCOOL® E Star DIY 4th Gen 24k BTU 208-230V/60Hz Ductless Mini-Split Air Handler

MRCOOL® E Star DIY 4th Gen 24k 208-230V/60Hz BTU Ductless Mini-Split Air Handler

Description

This product only includes an Air Handler (Indoor Unit).

The MRCOOL® 4th Generation DIY 24K BTU Ductless Wall Mounted Air Handler offers the performance you need to compliment your MRCOOL® DIY system. When connected to a MRCOOL® condenser, this air handler has the ability to reach a 20.5 SEER efficiency rating. It also has the power to deliver air to an area of up to 1,000 sq. ft. To make sure it can handle your needs, it is also equipped with multiple operating modes which include COOL, HEAT, AUTO, DRY (dehumidify), and SLEEP. With the use of the Smart HVAC app, it also has the ability to be operated from your Apple or Android smartphone. With its compact design and easy to use mounting plate, this air handler can be mounted to most interior walls. It is also meant to be used with the MrCool Pre-Charged Quick Connect Line Set to further the ease of installation. This line set is equipped with MrCool’s patented quick connectors, so it can be connected with use of only simple hand tools. It also precharged from the factory with the correct amount of R-410A refrigerant and requires no vacuuming once connected. The MrCool 4th Generation DIY 24 BTU Ductless Wall Mounted Air Handler is equipped with the power and performance to satisfy air conditioning needs of your home.

• SmartHVAC app: WIFI control - control your DIY anywhere with your Apple or Android smart device and an Internet connection
• Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty
• Compatible with Amazon Alexa and Google Assistant
• Includes the new DIY Pro™ Cable, an added safety feature to protect the wiring from the outside elements

Product Specifications

MRCOOL® E Star DIY 4th Gen 24k BTU 208-230V/60Hz Ductless Mini-Split Air HandlerProduct Specifications

COOLING CAPACITY	23000BTU
HEATING CAPACITY	25000 BTU
VOLTAGE	208-230 V
PHASE	1
CYCLE	60 Hz
MOUNT TYPE	Wall
COLOR	White
COLOR FAMILY	White
MAX COVERAGE AREA	Up to 1000 sqft
REFRIGERANT TYPE	R-410A
DECIBEL RATING	48.5/43.5/33
DECIBEL RATING LOW	33 dBA
DECIBEL RATING HIGH	48.5 dBA
INVERTER	Yes
MAX LINESET LENGTH	98.42 ft
LIQUID LINE SIZE	3/8 in
SUCTION LINE SIZE	5/8 in
BLOWER MOTOR RPM	1200/1000/700
FAN ONLY OPTION	Yes
QUIET MODE	Yes
AUTO COOL	yes
WIFI COMPATIBILITY	Yes
APP COMPATIBILITY	Yes
WORKS WITH IOS	Yes
WORKS WITH ANDROID	Yes
REMOTE CONTROL INCLUDED	Yes
ENERGY STAR CERTIFIED	Yes
AHRI CERTIFIED	Yes
REGISTERED WARRANTY	Limited Lifetime Compressor
BASE WARRANTY	5-year Parts/7-year Compressor
BASE PARTS WARRANTY	5-year Parts
REGISTERED COMPRESSOR WARRANTY	Limited Lifetime Compressor
BASE COMPRESSOR WARRANTY	7-year Compressor
HAS BATTERIES	Yes
CONTAINS ELECTRONICS	Yes
CONTAINS CHEMICALS	Yes
CONTAINS AEROSOL	Yes
CONTAINS COMPRESSED GAS	Yes
PROPOSITION 65 WARNING	Yes
RESTRICTED STATES	GU;PR;VI
NET DEPTH	8.90 in
NET HEIGHT	13.19 in
NET WIDTH	42.52 in
NET WEIGHT	35.27 lbs
GROSS DEPTH	19.57 in
GROSS HEIGHT	17.32 in
GROSS WIDTH	49.09 in
GROSS WEIGHT	60.19 lbs
