MRCOOL DIY® 5th Gen E Star 24,000 BTU Single Zone Mini Split Complete System with 25 Ft. Line Set, 230V (DIY-24-HP-WM-230D25-O)
MRCOOL DIY® 5th Gen E Star 24,000 BTU Single Zone Mini Split Complete System with 25 Ft. Line Set, 230V (DIY-24-HP-WM-230D25-O)
Description
Introducing the 5th Gen MRCOOL® DIY® 24K BTU Single Zone Mini-Split Air Handler for year-round heating and cooling in spaces 750 to 1,000 sq. ft. Easy DIY installation with included 25 ft. QuickConnect® line set and DIYPRO® cable. Customize comfort with wireless remote, SmartHVAC app, or voice commands. Industry-leading warranty for reliable, energy-efficient performance.
Features
- DIY Installation: Easy, tool-free setup with no prior experience required.
- DIY® QuickConnect® Line Set: Pre-charged with R-454B refrigerant for quick and vacuum-free installation.
- Environmentally Friendly Refrigerant: R-454B refrigerant has a lower Global Warming Potential (GWP) than older refrigerants like R-410A, reducing environmental impact while improving energy efficiency.
- DIYPRO® Cable: Eliminates the need for electrical conduit, offering enhanced durability against outdoor elements and wildlife.
- Wireless Control Options: Use the included remote, SmartHVAC app (Apple and Android), or voice commands via Amazon Alexa and Google Assistant.
- Follow Me Function: Maintains consistent comfort by adjusting airflow based on the remote’s location.
- Dry Mode: Acts as a dehumidifier to reduce excess moisture and improve indoor air quality.
- Gold Fin® Condenser: Provides corrosion resistance for coastal homes, ensuring long-lasting performance.
- Industry-Leading Warranty: Limited lifetime warranty, 7-year compressor warranty, and 5-year parts warranty.
- Certified Quality: Intertek listed 5031495 for reliable performance and safety.
Product Specifications
MRCOOL DIY® 5th Gen E Star 24,000 BTU Single Zone Mini Split Complete System with 25 Ft. Line Set, 230V (DIY-24-HP-WM-230D25-O) Product Specifications
| Dimensions & Weight | |
|---|---|
| Condenser Dimensions | 37.24 W" x 16.14 D" x 31.89 H" |
| Condenser Weight | 112.8 lbs / 55.7 kg |
| Air Handler Dimensions | 42.52 W" x 8.90 D" x 13.19 H" |
| Air Handler Weight | 35.49 lbs / 16.1 kg |
| Capacity & Performance | |
| Zone Capacity | 1 |
| Cooling Capacity | 23,000 BTU |
| EER2 | 12.7 |
| SEER2 | 22.7 |
| Heating Capacity | 23,000 BTU |
| HSPF2-4 | 9.6 |
| HSPF2-5 | 7.1 |
| Coverage Area | 750 to 1,000 sq ft. |
| Outdoor Noise Level | 58.5 dB(A) |
| Indoor Noise Level (Hi/Mi/Lo) | 54.0/48.0/43.0/33.5/20.0 dB(A) |
| Electrical Requirements | |
| Voltage | 208-230V |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 25A |
| Min Circuit Ampacity | 24A |
| Refrigerant & Piping | |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 67.37 oz |
| Liquid Line Size | 3/8" |
| Suction Line Size | 5/8" |
| Max Line Set Length | 164 ft. |
| Features | |
| Inverter | DC |
| Compressor Type | Rotary |
| Fan Only Option | Yes |
| Quiet Mode | Yes |
| Auto Cool | Yes |
| Wifi Compatibility | Yes |
| App Compatibility | Yes |
| Works with IOS | Yes |
| Works with Android | Yes |
| Remote Control Included | Yes |
| Certifications & Warranty | |
| Certifications | UL Listed, ETL Listed, Energy Star Certified, AHRI Certified |
| Warranty | 7 Years Compressor 5 Years Parts Extended Limited Lifetime Replacement *If the original owner does not register the unit, the warranty defaults to the standard 5 year parts, 7 year compressor warranty **The original, registered owner must be enrolled in the MrCool Care Program every year in order to qualify for the 7 year full unit replacement for compressor failure and lifetime compressor replacement. |
Product Manual
| Product Brochure |
| Installation Manual |
| Remote Control Manual |
| Warranty Document |
| AHRI Cert |
| Energy Guide |
Product Warranty
MRCOOL Limited Lifetime Warranty
LIMITATIONS OF WARRANTIES
Q1 How do I register my warranty?
Answer: Go to here to file your warranty.
Q2 How do I find the AHRI number of my unit?
Answer: You can find links to the AHRI certificates on the documentation page at mrcool.com/documentation.
