Aims Power Single Pole Mount Rack for 6 Solar Heavy Duty Panels

Aims Power Single Pole Mount Rack for 6 Solar Heavy Duty Panels

Description:

The AIMS Power Heavy Duty Solar Single Pole Mount Rack is made for the avid solar system seeker. Holding up to 6 large PV solar panels (up to 2.0 KW). This system can hold more panels depending on panel size. The heavy duty single pole rack is made of high quality, structural grade, corrosion resistant steel. The aluminum clamps and HD rails along with the stainless steel hooks and hardware provide the most durable single pole rack system on the market. This system includes everything needed for installation, except the actual concrete foundation to anchor the pole. The single pole mount installs quickly using special splicing kits, easy to use clamps and universal HD sliding rails. The rack can hold up to large 6 panels (265 watts and larger) and adjusts to four different degree angles. Changing the pole mount’s angle is easy using the convenient U bolt and pitman arm.

Product Specifications

Aims Power Single Pole Mount Rack for 6 Solar Heavy Duty Panels

Features

• Everything included except the concrete foundation

• Easy installation

• Modular

• Little measuring needed

• No drilling needed

• Pre-drilled holes for seasonal adjustments

• Universal HD sliding rails for easy solar panel mounting

• Convenient easy to use mounting clamps

• Beams and pole conform to ASTM A36

• Rails use 6000 series aluminum

• Stainless steel hardware

• Withstands wind speeds up to 102 mph

• Rust/corrosion resistant materials

• Seasonal elevation adjustment

• Four pitch degrees

• 15 Year manufacturer defect warranty

Specifications

Application

• Residential

• Farms

• Commercial

• Open areas

Materials

• Galvanized steel ASTM A36

• Stainless steel

• Aluminum

Tilt angles - 10°, 20°, 30°, 40°

Panel orientation – Portrait. Panel types: PV 60, 72 & 96 cell (all brands)

Wind tolerance – 102 mph

Snow load – 80 PSF *depends on characteristics of snow - standard

Requires concrete foundation 63" sq by 24" deep

Warranty– 15 Year manufacturer defect

Product Manual

AIMS Power Pole Mount Solar Rack - PV6X250POLE

Product Warranty

AIMS Power offers a one year warranty with all products. Follow the link below to register your product warranty:

https://www.aimscorp.net/product_registration.php

Product FAQs

AIMS Power FAQs
