RUiXU SUNON10 | 10kW Single/Split-Phase Off-Grid Inverter | UL1741
RUiXU SUNON10 | 10kW Single/Split-Phase Off-Grid Inverter | UL1741
Description
Standard Included
(1) SUNON10 10kW InverterĀ
(1) 200CM CAT6 Communcation cable connect with battery
(1) Operation manual
(1) Wifi dongleĀ
SUNON10 | RUiXU Single/Split-Phase Off-Grid Inverter | 10kW
The 10kW Split/Single-Phase Off-grid Solar Storage Inverter is designed to support both stand alone and hybrid grid modes. Built specifically for off-grid homes and commercial users, it is compatible with 48V storage batteries and features a powerful charging controller and parallel capability to meet higher power demands.
1. 48V Battery Compatibility
Compatible with 48V storage batteries, this inverter is suitable for flexible configurations in both home and commercial systems, supporting various lithium and lead-acid batteries.
2. Powerful 200A Solar Charging Controller
Equipped with a built-in solar charging controller with a maximum 200A charging current, this inverter ensures fast and stable battery charging, maximizing solar energy utilization.
3. SUB Mode Support (Grid and PV Hybrid Charging)
The inverter supports SUB mode, enabling hybrid charging from both grid power and solar PV. It automatically switches to grid power when solar energy is insufficient, ensuring reliable, 24/7 system operation.
4. Time-Scheduled Charge and Discharge
Users can set customized charging and discharging times with the inverter's time-scheduling feature, optimizing energy storage efficiency based on energy price fluctuations and usage needs, ultimately reducing electricity costs.
5. Supports Multiple Units in Parallel, Scalable to 60kW
The inverter allows up to 6 units to be operated in parallel, scaling the total power output up to 60kW. This setup is ideal for larger residential, commercial, and industrial off-grid power systems.
6. Built-in 200A Circuit Breaker
A built-in 200A circuit breaker provides overload and short-circuit protection for enhanced system safety and stability.
7. 120V/240V Split-Phase Output
The inverter supports both 120V output for small household appliances and 240V output for high-power equipment, offering flexibility to meet a wide range of power needs.
8. 3-Year Warranty
This inverter comes with a 3-year warranty, ensuring product quality, long-term stability, and reliable performance for users.
Product Specifications
RUiXU Single/Split-Phase Off-Grid Inverter | SUNON10 | 10kW | UL1741 Product Specifications
| Category | Specification |
|---|---|
| MODEL | |
| Max. Output Power | 20,000VA |
| Rated Output Voltage | 120/240 Vac (single-phase/split-phase) |
| Load Capacity of Motors | 6 HP |
| Rated Frequency | 50/60Hz |
| Output Wave | Pure sine wave |
| Switching Time | 10ms (typical value) |
| INVERTER OUTPUT | |
| Battery Type | Lithium-ion battery / Lead-acid battery / User-defined battery |
| Rated Battery Voltage | 48V |
| Voltage Range | 40~60Vdc |
| Max. Solar Charging Current | 200A |
| Max. Grid/Generator Charging Current | 120A |
| Max. Mix Charge Current | 200A |
| BATTERY | |
| No. of MPPT | 2 |
| Max. Input Power | 11,000W |
| Max. Input Current | 22/22A |
| Max. Open Circuit Voltage | 550Vdc |
| MPPT Voltage Range | 125~425Vdc |
| SOLAR INPUT | |
| Input Voltage Range | 90~140Vac |
| Input Frequency Range | 50/60Hz |
| Bypass Overload Current | 63A |
Product Manual
RuiXU Product Manual
Product Warranty
10 Years Warranty
All RUiXU batteries come with 10 years warranty.
RUiXU stand behind the quality and durability of our products.
Quality Assurance
RUiXU take pride in our relentless commitment to delivering products of the highest quality. Our rigorous quality assurance processes ensure that every item leaving our facilities meets the strictest standards.
Local Warehouse
Swift Shipping for Your Convenience
With our strategically located local warehouse, we bring convenience right to your doorstep. Enjoy expedited shipping within 3 business days.
Expert and Timely Technical Service Team
Your Reliable Support Partner
Our expert technical service team is dedicated to providing you with unparalleled support when you need it most. we promise all questions will be answered within 24 hoursĀ
Product FAQs
N/A
