MRCOOL® GeoCool 60K BTU 5T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor
MRCOOL® GeoCool 60K BTU 5T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor
Description
Prepare to enjoy impressive performance and exceptional energy efficiency with the MRCOOL® Geocool® Geothermal Split System Compressor. With an all DC inverter system and a high precision electronic expansion valve, you can expect a much quieter, stable, and energy-saving experience with more accurate temperature control than with standard heating and cooling systems. The open loop water-to-air system’s superb energy efficiency boasts up to 70 EER, significantly lowering utility costs. Installation is easy with the compatible MRCOOL® Geocool® No-Vac® Line Set. The system features multiple flexible installation options including vertical, horizontal, and split configurations. This makes this system an excellent solution if your home has space constraints or requires modification to a different air outlet method. The compressor features multiple protections against potential damage along with a reliable and durable build and finish. The co-axial copper-nickel heat exchanger makes the system suitable for salt solution and lower water quality, and improves corrosion resistance and unit reliability. With a cooling noise level as low as 58dBA and heating noise level as low as 60dBa, you’re able to enjoy superior comfort without any distraction. For peace of mind, this MRCOOL® Geocool® Geothermal Split System Compressor offers a 10-year parts warranty as well as a 5-year limited labor warranty.
Product Specifications
MRCOOL® GeoCool 60K BTU 5T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor Product Specifications
| Brand Name | GeoCool |
|---|---|
| Series | GeoCool Inverter Series |
| Model | GCSHPM060IN |
| GTIN | 00840255577977 |
| UPC | 840255577977 |
| Unit Type | Geothermal Heat Pump |
| Equipment Type | Compressor |
| Configuration | Multi Positional |
| Short Description | GeoCool 60K BTU 5T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor |
| EER | Up to 70 |
| Voltage (V) | 208 / 230 |
| Cooling Capacity (BTU) | 62000 |
| Heating Capacity (BTU) | 55600 |
| Voltage (V) | 208/230 |
| Phase | 1 |
| Cycle | 60 |
| Max Fuse Breaker (A) | 35 |
| Min Circuit Ampacity (A) | 26 |
| Color | Gray |
| Color Family | Gray |
| Refrigerant Type | R-410A |
| Inverter | DC |
| Liquid Line Size | 3/8 |
| Suction Line Size | 3/4 |
| Compressor Type | Rotary Inverter |
| Refrigerant Type | R-410A |
| Refrigerant Volume (Oz) | 35.27 |
| Base Parts Warranty | 10 years |
| Base Labor Warranty | 5 Year Limited |
| Overload Protection | Yes |
| UL Listed | Yes |
| Energy Star Certified | Yes |
| AHRI Certified | Yes |
| Has Batteries | No |
| Contains Electronics | Yes |
| Contains Chemicals | Yes |
| Contains Aerosol | Yes |
| Contains Compressed Gas | Yes |
| Proposition 65 Warning | Yes |
| Net Depth (In) | 22.44 |
| Net Height (In) | 25.12 |
| Net Width (In) | 24.80 |
| Net Weight (Lbs) | 231.53 |
| Gross Depth (In) | 27.56 |
| Gross Height (In) | 30.71 |
| Gross Width (In) | 28.54 |
| Gross Weight (Lbs) | 254 |
Product Manual
MRCOOL® GeoCool 60K BTU 5T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor Installation Manual
Product Warranty
MRCOOL Limited Lifetime Warranty
LIMITATIONS OF WARRANTIES
Q1 How do I register my warranty?
Answer: Go to here to file your warranty.
Q2 How do I find the AHRI number of my unit?
Answer: You can find links to the AHRI certificates on the documentation page at mrcool.com/documentation.
Q3 I have not received my free SWAG item yet, has it been shipped?
Answer: Orders typically take 4 to 6 weeks to process and ship. If you have not received your Swag order within 8 weeks – please, contact us via email at [email protected]
