Mastervolt CombiMaster Inverter/Charger - 24/3500-100 Amp - 120V [35523500]
Mastervolt CombiMaster Inverter/Charger - 24/3500-100 Amp - 120V [35523500]
Unmatched performance at an unprecedented price
Designed with the customer in mind and using the latest technology, the CombiMaster range is all about user-friendliness and reliability. But don’t let that friendly appearance misguide you: the powerful CombiMaster range drives even the heaviest and most sensitive loads with ease!
With the CombiMaster, power dips and failures belong to the past. The automatic AC transfer system switches between generator or mains and inverter output, ensuring a constant power supply. Its Power Assist function prevents tripping of the mains fuse in case you’re connected to a weak land line or small generator.
The CombiMaster range delivers unmatched performance and value for money. As you would expect from Mastervolt, the CombiMaster is completed with MasterBus, CZone and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options.
Remote Control and Monitoring options
- MasterBus compatible via SmartRemote or EasyView 5 display.
- CZone / NMEA 2000 compatible via Touch 5 or Touch 10 display.
- NMEA 2000 compatible via 3rd party multifunctional display.
Parallel and Split-phase operation
The CombiMaster 3500/4500/5000 functionality goes beyond stand-alone operation, the design also allows parallel and split phase configurations for larger applications up to 35 kW.
Features
- Most compact and lightweight Combi in its class.
- Reliable, hum-free and longer operation from your batteries.
- Starts even the heaviest and most sensitive loads.
- Intelligent 3-step+ battery charger for faster and safer charging.
- Automatic switching between mains and inverter mode.
- Power Assist prevents blown mains fuses.
- Generator compatible.
- Integrated CZone, MasterBus and NMEA 2000 communication.
- Quick installation with heavy duty connections.
Product Specifications
Mastervolt CombiMaster Inverter/Charger - 24/3500-100 Amp - 120V [35523500] Product Specifications
| Category | Specification |
|---|---|
| Nominal DC Voltage | 24 V (20.4–32 V) |
| Output Voltage | 120 V |
| Output Frequency | 60 / 50 Hz (configurable) |
| Output Waveform | True sine |
| Continuous Power (40 °C) | 3500 W |
| Peak Power (30 sec) | 5250 W |
| Surge Power (5 sec) | 7000 W |
| Max Efficiency | 93% |
| No-Load Consumption | 47 W (on) / < 1 mA (off) |
| Energy Saving Mode | 25 W |
| Synchronise with Mains | Yes |
| Battery Charger Input Voltage | 90–140 V |
| Max Input Current | 32 A (adjustable) |
| Max Charge Current (40 °C) | 100 A at 28.5 V (configurable) |
| Battery Temp Sensor | Yes, included |
| Battery Voltage Sense | Automatic compensation |
| AC Input (Transfer System) | 50 A (max, switched) |
| AC Output (Transfer System) | 85 A max |
| AC Input Fuse | Yes |
| Transfer Speed | 10 ms |
| Transfer Voltage Range | 90–140 V |
| Transfer Frequency Range | 40–65 Hz |
| Galvanic Isolation | Yes |
| Display | LED display |
| Dimensions (H×W×D) | 568 × 359 × 170 mm (22.4 × 14.1 × 6.7 in) |
| Weight | 17 kg (37.5 lb) |
| Charge Characteristic | UoUo, automatic / 3-step+ for Flooded, Gel/AGM, MLI (configurable) |
| Recommended Battery Capacity | 200–1000 Ah (Gel basis) |
| Ground Relay | Yes, configurable via mechanical jumper |
| Operating Temperature | –25 °C to 60 °C (derating above 40 °C, shutdown above 60 °C) |
| Cooling | Vario fan |
| Ingress Protection | IP23 (vertical mounting) |
| Safety Class | IEC Class I |
| Humidity Protection | Conformal coating, up to 95% RH (non-condensing) |
| Protections | Over-temp, overload, short circuit, high/low battery voltage |
| Power Assist | Yes |
| Power Sharing | Yes |
| MasterBus Compatible | Yes |
| CZone / NMEA 2000 Compatible | Yes |
