Huum CLIFF 9, 9.0kW Sauna Heater

Huum CLIFF 9, 9.0kW Sauna Heater

Description

The CLIFF 9.0kW sauna heater is a slim electric sauna heater with remarkably small safety distances, which makes it perfect for saunas with limited spaces. The CLIFF 9.0kW sauna heater is designed for sauna spaces up to 529 cubic feet (CF).

Required Control and sauna stones (5 boxes) sold separately

• Slender design
• Suitable for use in small saunas with limited space
• Small safety distances
• Heats up to 25% faster due to internal air duct
• For sauna rooms from 317 to 529 cu. ft.
• Works with UKU controls (sold separately)
• 165 pound stone capacity (required 5 boxes sold separately)
• Removable rib(s) for more accurate stacking of stones
• Direct contact between stones and heating elements
• More exposed stones creates a longer and milder heat
• Stainless steel construction
• Stainless steel, industrial quality heating elements
• Floor model
• Designed, engineered, and made in Estonia
• Dimensions: 10.6" W (270mm) x 10.6" D (160mm) x 38.4" H (975mm)
• Limited 5-year warranty (excluding elements)

Product Specifications

Huum CLIFF 9, 9.0kW Sauna Heater Product Specifications

PACKAGE CONTENTS	9.0kW sauna heater 2 prop blocks (for removal of sauna rib slats) Installation and operation manual 5-Year limited warranty (excluding elements)
OPTIONAL ACCESSORIES	Rail C, Reflect C, Flange CS
COMPATIBLE SAUNA CONTROL	UKU
WEIGHT	35 lbs (15.87kg)
LENGTH / WIDTH	11.25" (285.8mm)
WIDTH / DEPTH	11.25" (285.8mm)
HEIGHT	38.25" (971.5mm)
DIAMETER	N/A
DIMENSIONS	11.25" W (285.8mm) x 11.25" W (285.8mm) x 38.25" H (971.5mm)
KW	9.0
WATTS	9000
VOLTS	240
AMPS	37.5
PHASE	1PH
ROOM VOLUME (CU. FT.)	317 - 529 CU. FT.
ROCK CAPACITY	165 lbs



Product Manual

CLIFF Installation Manual

CLIFF Spec Diagram

Product Warranty

HUUM Heater Warranty

Limited 5-Year Warranty (excludes heating elements)

Product FAQs

N/A
