Description

Growatt 5000-US multifunctional off-grid solar inverter, integrated with a MPPT solar charge controller, a high-frequency pure sine wave inverter, and a UPS function module all in one machine. Perfect for off-grid backup power and self-consumption applications.

Key Features:

• Rated power 5KW, power factor 1
• MPPT ranges 120V~430V, 450VDC
• High-frequency inverter with small size and lightweight
• Pure sine wave AC output
• Solar and utility grid can power loads at the same time
• With CAN/RS485 for BMS communication
• Parallel operation up to 6 unit (only with battery connected)
• WIFI/ GPRS remote monitoring (optional)

Included:
(1) Paralleling Kits
(1) Communication Cable

Please note: We recommend using this inverter with batteries.

Product Specifications

Growatt 5kW Stackable Off-Grid Inverter | SPF 5000US | UL 1741 Product Specifications

Specification	Details
Rated Output Power	5,000W (5kW)
Surge Power	10,000W
Battery Voltage	48V nominal (operates between 40–60V)
AC Output Voltage	240V AC (requires ATS for 120V loads)
Max PV Input Power	6,000W
MPPT Operating Voltage	120–430V DC
Max Solar Charge Current	100A
AC Charge Current	80A
Parallel Capability	Up to 6 units (requires battery connection)
Efficiency	Up to 93% (peak)
Transfer Time	10ms typical, 20ms max
Dimensions (W x H x D)	Not specified
Weight	Not specified
Battery Compatibility	Lithium and lead-acid batteries
Communication Ports	CAN/RS485 for Battery Management System (BMS)
Monitoring Options	Optional WiFi/GPRS remote monitoring via Growatt ShineLink

Product Manual

Growatt Data Sheet

Growatt User Manual

Product Warranty

Growatt Warranty

Service terms & conditions.

(1)Product coverage: Including Growatt PV Inverters, Growatt Storage Inverters, Growatt Smart Energy Management Devices, Growatt Monitoring Software, EV Chargers, Portable Power Station and Growatt Batteries and Accessories

(2)Country and Region coverage: All country and regions, including China Hong Kong special administration region, Macao special administration region, Taiwan, excluding mainland China ONLY. Warranty coverage is contingent upon the alignment of the country of sale, the country of installation, and the country of after-sales service.

(3)Warranty claim: In general, serial number(S/N）must be provided in order to claim warranty. Please store the original purchasing invoice/ installation documents or receipts carefully. Customers need to present it for warranty claim if required.

(4)Warranty period: The standard warranty period is from the date of installation on the installation certificate and no more than six months after the delivery date from Growatt. A warranty extension may only be applied within a period of two years from the date of installation.

Growatt service commitment

(1) The service hotline for Growatt local service center varies, please check our local service center in your country/region. The service hotline in Shenzhen headquarter is +86 755 27471942. Our service hotline offering general inquiry, technical support, etc.

(2) Service email address: [email protected]. Customer is suggested to contact Growatt service representative in your country/region directly.

(3) Warranty period and service mode. We offer different service solutions for different product, see details on below table

Note: If warranty period was specified on sales order, then warranty period would obey to sales order.

(4) Installation and commissioning：Growatt don’t offer installation service, don’t offer onsite debugging service for monitoring device. Growatt can offer onsite commission service for big scale plant (inverter capacity＞500kw)
