Canadian Solar EP Cube Hybrid Inverter | 7.6kW
Canadian Solar EP Cube Hybrid Inverter
Description
Canadian Solar EP Cube Hybrid Inverter
The EP Cube's 7.6kW hybrid inverter is designed to seamlessly integrate with your modular battery system. The inverter neatly attaches to the top of the battery bank, making it easy to install and operate. With the integrated hybrid inverter, the EP Cube is suitable for both new and installed PV systems. It also supports AC output, PV + battery, and battery-only options, allowing you to choose the best option for your home's energy needs.
Ā From unboxing to install, weāre with you every step. Reach out to our lifetime, USA-based support team anytime you need guidance.
Product Specifications
Canadian Solar EP Cube Hybrid InverterĀ Product Specifications
| Feature | Details |
|---|---|
| Model | EP Cube Hybrid Inverter (e.g., NA510G, NA613G, NA716G, NA720G) |
| Inverter Type | Hybrid (AC and DC input) |
| Maximum AC Output | 7.6 kW (on-grid) |
| Nominal Grid Voltage | 240 VAC |
| Frequency | 60 Hz |
| MPPTs (Maximum Power Point Trackers) | 2 or 4 (depending on model) |
| Maximum DC Input Voltage | 600 VDC |
| MPPT Operating Voltage Range | 90ā550 VDC |
| Input Current per MPPT | 16 A (maximum) |
| Allowable DC/AC Ratio | Up to 2:1 |
| CEC Efficiency | 93.93% |
| Battery Compatibility | Lithium Iron Phosphate (LiFePOā) modules |
| Battery Capacity | 9.9 kWh to 19.9 kWh per unit, up to 119.9 kWh for full system |
| Enclosure Rating | IP65 (dust-tight and protected against water jets) |
| Certifications | UL 1699B, UL 1741-SB, IEEE 1547, IEEE 2030.5 |
| Warranty | 10 years or 6,000 cycles (whichever comes first) |
Product Manual
Canadian Solar EP Cude Data SheetĀ
Canadian Solar EP Cude Installation Guide
Product Warranty
Canadian Solar EP Cube Warranty
Product FAQ's
N/A
Original: $3,000.00
-65%$3,000.00
$1,050.00Product Information
