Simrad NSS7 evo3 Chartplotter/Fishfinder with Insight Charts [000-13233-001]

Simrad NSS7 evo3 Chartplotter/Fishfinder with Insight Charts [000-13233-001]

Simrad NSS7 evo3 Chartplotter/Fishfinder with Insight Charts [000-13233-001]

Description

Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX™ HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 7-inch widescreen SolarMAX™ HD display.
Features:

  • Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
    Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
  • Add StructureScan® 3D imaging, advanced Broadband Sounder™ capabilities and more via Simrad modules
  • Expand your view with Halo™ Pulse Compression radar, Broadband 3G™/4G™, and other Simrad radar solutions
  • Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
  • NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
  • Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
  • Enjoy easier trip planning with TripIntel™ technology and support for
  • Navionics Autorouting/C-MAP Easy Routing (automatic routing unavailable in North America)
  • Built-in GoFree™ Wi-Fi enables online features and smartphone monitoring/tablet control
  • Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
  • Includes Insight chart
  • Dimensions without bracket and knobs: 9.41"w x 5.90H
  • Dimensions with brack and knbos: 10.35"w x 6.31"h

Product Specifications

Simrad NSS7 evo3 Chartplotter/Fishfinder with Insight Charts [000-13233-001] Product Specifications

Specifications:

Physical

  • Dimensions W x H x D: 239 x 150 x 90 mm (9.4 x 5.9 x 3.5")

  • With Bracket: 263 x 161 x 93 mm (10.35 x 6.31 x 3.66")

  • Mounting Type: Bracket (supplied) or panel mount

  • Weight: 1.1 kg (2.42 lbs)

  • Screen Size: 7"

  • Touchscreen: Yes

  • Cartography Brand: Navionics/C-Map/Lowrance/CMOR

  • Transducer Included: No

  • Box Dimensions: 9"H x 9"W x 13"L

  • WT: 6.85 lbs

  • UPC: 9420024154038

Display

  • Backlight Color: White

  • Display Resolution: 600 x 1024

  • Viewing Angles: 80° top/bottom, 80° left/right

Electrical

  • Power Consumption max: 20 W

  • Recommended Fuse Rating: 3 A

  • Supply Voltage: 10 – 31.2 V DC

Environment

  • Operating Temperature Range: -15°C to +55°C (5° F to 131°F)

  • Storage Temperature Range: -20°C to +60°C (4°F to 140°F)

  • Waterproof Rating: IPX6 and 7

Connectivity

  • Bluetooth: Internal

  • Ethernet Ports: 1 x 5-pin yellow connector x 1 Mbit

  • Wi-Fi: Internal

  • NMEA 2000: 1 x NMEA 2000 Micro-C port, 1 LEN

  • NMEA 0183 Sentences Supported: Input GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, HDT, HDM, MWV, MWD, DSC, DSE, VDM; Output GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, MWV, MWD, TLL, TTM

MFD Features

  • AIS: Receive AIS data over NMEA 2000 or NMEA 0183

  • Autopilot: Full autopilot control and commissioning

  • Cartography Included: Insight

  • Digital Switching: BEP C-Zone, Naviop

  • GPS: Internal, 16 GB storage

  • Multimedia: Via SonicHub2, FusionLink, Sirius (*USA only), JL Audio (**AUST & NZ only)

  • Sonar Compatibility: Two 9-pin Xsonic Sonar ports (CHIRP, HDI, TotalScan, LSS HD, ForwardScan)

  • Waypoints, Routes, Tracks: 6000 waypoints, 500 routes (100 max points), 50 tracks (12,000 max points)

  • Weather: SiriusXM via WM-3 (USA only), GRIB

GPS

  • Correction: WASS, MSAS, EGNOS, GLONASS

  • Receiver Channels: 34

  • Position Accuracy: Horizontal 3 m (9.8 ft)

  • Time to First Fix: Cold start 50 sec, satellite reacquisition 5 sec

  • Update Rate: 10 Hz

Autopilot

  • Maneuvers Turn Patterns: U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking

  • Steering Modes: Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, *Wind, *Wind NAV (*Boat type set to Sail)

Approvals

  • CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002, EN 300 440-2, V1.4.2

Other

  • Interface: Full touchscreen (multi-touch) and full keypad control, OP50 remote controllers

  • Languages: English(US), English(UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Swedish. Unlockable: Japanese, Korean, Thai, Chinese, Bulgarian, Hebrew, Croatian, Hungarian, Lithuanian, Latvian, Polish, Slovak, Turkish, Russian, Ukrainian, Arabic, Farsi

  • Warranty Period: 2 Years

Product Manual

NSS evo3 Installation Manual

NSS evo3 Quick Start Guide

NSS evo3 Operator Manual

Product Warranty

Simrad Warranty

Product FAQ's

N/A
