Lowrance NEP-2 Network Expansion Port [000-10029-001]

Lowrance NEP-2 Network Expansion Port [000-10029-001]

Lowrance NEP-2 Network Expansion Port [000-10029-001]

Description

Lowrance NEP-2 Network Expansion Port-2 plug-and-play hub for high-speed data-sharing of multiple HDS, LCX,and LMS products with ethernet modules, like the LWX-1 SIRIUS Satellite Radar and Radio module and the Broadband Sounder module across the onboard network. Lowrance NEP-2 Waterproof expansion ports resist corrosive marine environments. Unused expansion ports capped for future expansion.

Product Specifications

Lowrance NEP-2 Network Expansion Port [000-10029-001] Product Specifications

Feature Specification / Details
Product Name Lowrance NEP-2 Network Expansion Port
Part Number 000-10029-001
Type Marine Ethernet Switch
Ethernet Ports 5 (for displays and accessories)
Power Supply 9.5–32 V DC (12/24 V compatible)
Water Resistance IPX7 (waterproof to 1 meter depth for 30 minutes)
Operating Temperature -28°F to 167°F (-33°C to 75°C)
Dimensions (WxHxD) 8.3" x 2.3" x 7.4" (210 mm x 57.6 mm x 188 mm)
Weight 1.82 lbs (0.825 kg)
Mounting Style Panel or dashboard mount
Compatibility Lowrance HDS, LCX, LMS series; Simrad NSE series; compatible with Ethernet modules like LWX-1 SIRIUS Satellite Radar and Radio module, and Broadband Sounder module

Product Manual

N/A

Product Warranty

Lowrance Limited Warranty

Navico warrants that its products, when properly installed and used, will be free from defects in material and workmanship for the period stated for the applicable product and/or peripheral device as set out in the Warranty Period Matrix from the date of first purchase (the Warranty Period).

For the purpose of this Warranty, ’date of first purchase’ means the date the product was purchased by the first retail customer; or in the case of a product installed on a new vessel by a Certified/Approved Lowrance/ Navico Boat Builder, the date the first retail customer took delivery of the vessel.

Navico will, at its sole discretion, repair or replace with new or refurbished parts or product, or equivalent product, any proven defective products or components returned to Lowrance/ Navico, or its approved agent during the Warranty Period in accordance with the terms, conditions and limitations as set out in theĀ Navico Warranty Policy. Such repairs or replacements will be the sole remedy of the customer under this Warranty.

Lowrance Electronics manufactures units specifically for sale in the Americas and units specifically for sale to the Rest of the World (ROW). These units are certified to different standards for different markets. Lowrance Americas-based products will go into a limited features mode, when crossing a defined meridian (30 degrees West longitude or the International dateline to the East). Customers should purchase units from local authorized Lowrance/Navico dealers and distributors – this will ensure that customers receive products which are safe and useful for their requirements. In addition, customers who experience a problem can receive prompt local service and support. Contact us for more information.

Product FAQ's

N/A
