Description

The Dimplex DSH20W Series Reflective Infrared Heater compliments your surroundings with heat and lighting all at the same time. With an IP 65 rating, it is suited to be used indoors or outdoors.  It is hardwire-ready and mounted on the wall using the mounting kit that comes with the heater or a choice to be mounted with a ceiling bracket or pole stand (sold separately).

With its powerful ability to reach maximum temperature in less than 3 seconds, The heaters can provide comfort to your guests fastly than most comparable heaters.

The handheld remote control is available allowing easier control. With three heat settings, you can easily get the right amount of heat to stay warm and comfortable. Turn it on and forget about it, this heater is equipped with a safety mechanism and will automatically turn off after 8 hours.

Constructed with corrosion-resistant anodized aluminum and 304 stainless steel makes this product is protected for all climates.

Features

• IP65 rating for indoor and outdoor applications
• 1,2 and 3-hour delay time
• 8-hour auto-shutoff safety mechanism
• 3-second maximum heat-up time
• 3 temperature settings - 1000W [low], 1500W [med], 2000W [high]
• Corrosion-resistant anodized aluminum and 304 stainless steel make this product suitable for all climates
• Multiple heaters can be controlled with a single remote. Remote control included
• Each heater comes with the element pre-installed, which eases installation and reduces the risk of damaged, broken, or misplaced elements upon delivery

*Comes with a single heater and remote control. Ceiling Mount Bracket (DSHCMB) and Floor Mounted Tower Kit (DSHSTAND) are sold separately

Product Specifications

Dimplex Outdoor/Indoor Electric Infrared Heater Product Specifications

Attribute	Details
Finish	Aluminium
Volts	240V
Wattage	1000-2000W
BTUs	6824
Amps	8.3
Approvals	cULus
Construction	Stainless Steel
Heating Area	125 sq. ft.
Product Dimensions (inches)	H 6 in x W 23 1⁄2 in x D 12 13⁄16 in
Product Dimensions (cm)	H 15.24 cm x W 59.6 cm x D 32.6 cm

Product Manual

Dimplex Product Brochure

Dimplex Product Specs Sheet

Dimplex Product Manual

Product Warranty

Dimplex Product Warranty

Your purchase is covered by the Manufacturer’s Limited Warranty. View full Manufacturer Limited Warranty below.

Dimplex Warranty

Return Shipping

The consumer is responsible for all “Product Return Shipping” carrier fees, except if the unit is defective, damaged upon receipt or if the wrong product is shipped. We will cover the return shipping costs directly seven (7) days after delivery if the product was delivered damaged, seven (7) days after delivery if the wrong product was shipped from Glen Dimplex Americas or thirty (30) days after delivery for concealed damage or defective.

The consumer will be responsible for all “Product Return Shipping” carrier fees relating to buyer’s remorse or if the consumer ordered the incorrect model and require a replacement. A 25% restocking fee will apply.

Product FAQs

Dimplex Product FAQs

How do I know what part I need for my Dimplex unit?

Troubleshooting Guides and Replacement Parts lists are located in the Parts and Service Manual which is included in the original packaging along with the product. If this is lost or misplaced, these manuals can be found by entering the model number found on the unit in the search field in the Product Downloads section. If you have any questions, you can email our customer service team. Please include your model number and serial number so we can assist you quickly and efficiently.

How do I tell if my existing unit is a Dimplex unit?

Most Dimplex fireplaces say Dimplex on them somewhere. Other brand names we have sold under were Electrolog, Symphony, and Optiflame. If you need some assistance you may Contact Us.

Please have your model number and serial number available so we can assist you efficiently.
