ARCO Marine Original Equipment Quality Replacement Mercury Power Tilt Trim Assembly - 30HP-60HP [6800]

ARCO Marine Original Equipment Quality Replacement Mercury Power Tilt Trim Assembly - 30HP-60HP [6800]

Replacement outboard tilt trim assembly that will fit Yamaha 225HP-250HP, 1993-2003.

ARCO advises cleaning all connections: A corroded connection creates resistance, lowering the amperage required to operate the motor.

Features:

• Tilt trim motors are dynamically tested to ensure out-of-the-box performance
• Motor shafts induction case hardened at bearing surfaces for superior wear resistance
• Epoxy Powder coated for maximum insulation protection

Product Specifications

ARCO Marine Original Equipment Quality Replacement Mercury Power Tilt Trim Assembly - 30HP-60HP [6800] Product Specifications

Technical Specifications:

• Part Number: 6800

• Application: Mercury outboard engines, 30–60 HP (model years 1999–2014)

• Replaces OEM Assemblies:

  • Mercury 8M0055006

  • Mercury 893518T01

  • Mercury 830150T10

  • Mercury 830150T6

  • Mercury 830150T4

• Motor Type: Power Tilt/Trim Pump Assembly

• Construction:

  • Epoxy powder-coated housing for corrosion resistance

  • Induction-case hardened motor shafts for durability

• Tested Performance: Dynamically tested for out-of-the-box reliability

• Box Dimensions: 17″ × 11″ × 5″; Weight ≈ 13 lb

• UPC: 693006010908

• Warranty:

  • 12 months for leisure use

  • 90 days for commercial/racing use

  • +1 year extended warranty (rotating parts) if registered within 30 days

Product Manual

Owner's Manual

Product Warranty

ARCO Marine Warranty

Warranty Information:

When properly installed, all ARCO products are warrantied against defects in materials and workmanship for a period of 12 months for leisure use and 90 days for commercial or racing applications.

Add an extra year of warranty to your rotating electric ARCO product (Tilt/Trim Motors, Alternators, Outboard Starters, and Inboard Starters) when you register your product within 30 days of purchase. You can register your product by visiting arcomarine.com/product-registration

Replaces:

• MERCURY Power Trim Assembly 8M0055006
• MERCURY Power Trim Assembly 893518T01
• MERCURY Power Trim Assembly 830150T10
• MERCURY Power Trim Assembly 830150T6
• MERCURY Power Trim Assembly 830150T4

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Product FAQs

N/A
