American Hearth Rushmore 35" Clean Face Direct Vent Fireplace
American Hearth Rushmore 35" Clean Face Direct Vent Fireplace
Description
A Direct-Vent system uses two vent pipes. One draws air in from outdoors to support combustion. The other exhausts the by-products of combustion to the outside. The two vent pipes may be concentric (exhaust pipe within a larger diameter intake pipe) or co-linear (separate pipes of about the same size).
Combustion takes place inside a sealed chamber – with a glass front in the case of a fireplace. Room air circulates around the combustion chamber, often assisted by a blower, to heat the room.
A DV system is often installed along an outside wall to simplify the vent run, but can also be installed elsewhere in the home and vented through the roof.
Rushmore Direct-Vent Inserts
A Direct-Vent Fireplace Insert turns your existing wood-burning fireplace into an efficient gas-fired heat source. Direct-Vent Fireplace Inserts are classified as zone heating appliances. Zone heating is inherently more efficient than your existing wood-burning fireplace or your central furnace.
Rushmore Clean-Face Direct Vent Insert (DVCT35CBN)
Rushmore fireplace inserts feature the TruFlame system – a combination of technology and aesthetics to create realistic flames and a glowing ember bed, mimicking a natural wood fire. Available in two sizes, 30 and 35, these inserts turn your wood-burning fireplace into an attractive and efficient focal point. The multifunction remote operates as a conventional thermostat, a Smart Thermostat – which modulates flame height as the room reaches the desired temperature, or as a manual control. The remote also operates the included accent light and blower.
Features
- Includes Fireplace Barrier Screen
- 3 x 4 Venting
- Log Set Required
- Ceramic Glass: 31-3/4 x 28-3/8
- Manually Variable Valve
- TruFlame Technology
- Multi-Function Variable Flame Height Remote
- Installs as an insert in an existing fireplace
- Weight: 124 lbs.
- Maximum BTU Output: 35,000
- Min/Max Natural Gas Inlet Pressure: 4.5"/14" WC
- Min/Max Propane Gas Inlet Pressure: 10.8"/14" WC
- Minimum Fireplace Dimensions: 35 1/4" W x 24 1/2" H x 19" D
- Actual Viewing Area: 29 1/4" W x 19 7/8" H
- Valve Type: IPI Valve
Product Specifications
American Hearth Rushmore 35" Clean Face Direct Vent Fireplace Product Specifications
| Attribute | Details |
|---|---|
| Model | DVCT35CBN95 |
| Fuel Type | Natural Gas / Propane |
| Vent Type | Direct Vent |
| Valve Type | IPI Valve |
| Input BTU/HR (Max/Min) - Propane | 35,000 / 12,000 |
| Input BTU/HR (Max/Min) - Natural Gas | 39,000 / 11,000 |
| Weight | 124 lbs |
| Ceramic Glass Dimensions | 20 1/4" x 29 1/2" |
| Venting | 3 x 4 Flex |
Product Manual
American Hearth Download Installation Guide
American Hearth Product Brochure
American Hearth Owner's Manual
American Hearth Download Architecture
American Hearth Rushmore Clean-Face Direct-Vent Liner Kits
Product Warranty
American Hearth Product Warranty
10-year Limited Warranty on Combustion Chamber, Limited Lifetime on Glass. All other parts carry a three-year limited warranty. All remote controls and lighting systems carry a one-year limited warranty.Â
Product FAQs
American Hearth Product FAQs
Can I buy a fireplace online and install it myself?
Does our product work during a power outage?
What is the difference between, Millivolt and electronic ignition fireplaces?
Can I use a Wi-Fi Thermostat with my unit?
Where can I find my model and serial number?
Can you tell me how old my unit is?
Once you locate your rating plate the serial number will help identify the age, the first two digits of the serial number denote the year of manufacture (21, 20, 19...) the next two digits identify the week of that year that the unit was built.
