American Hearth TrueFlame 30" Multifunction Clean Face Direct Vent Fireplace
American Hearth TrueFlame 30" Multifunction Clean Face Direct Vent Fireplace
Description
This fireplace inserts feature the TruFlame system – a combination of technology and aesthetics to create realistic flames and a glowing ember bed, mimicking a natural wood fire. Available in two sizes, 30 and 35, these inserts turn your wood-burning fireplace into an attractive and efficient focal point. The multifunction remote operates as a conventional thermostat, a Smart Thermostat – which modulates flame height as the room reaches the desired temperature, or as manual control. The remote also operates the included accent light and blower.
Features
- Size: 30"
- Color: Black
- Product Dimensions: 30 11/16" W x 19" H x 17 9/16" D
- Fuel: Natural Gas or Liquid Propane
- Insert will install into an existing fireplace
- 30" direct-vent insert with TruFlame technology
- Remote controls flame height, lighting, and variable-speed blower
- Maximum BTU Output: 28,500
- Min/Max Natural Gas Inlet Pressure: 4.5"/14" WC
- Min/Max Propane Gas Inlet Pressure: 10.8"/14" WC
- Valve Type: IPI Valve
Product Specifications
American Hearth TrueFlame 30" Multifunction Clean Face Direct Vent Fireplace Product Specifications
| Attribute | Details |
|---|---|
| Model | DVCT30CBN95 |
| Actual Dimensions | 30 11/16" W x 19" H x 17 9/16" D |
| Fuel Type | Natural Gas / Propane |
| Vent Type | Direct Vent |
| Valve Type | IPI Valve |
| Input BTU/HR (Max/Min) - Propane | 28,500 / 10,000 |
| Input BTU/HR (Max/Min) - Natural Gas | 30,000 / 8,500 |
| Weight | 98 lbs |
| Ceramic Glass Dimensions | 15 1/4" x 25 1/2" |
| Venting | 3 x 4 Flex |
Product Manual
American Hearth Product Installation Guide
American Hearth Product Brochure
American Hearth  Owner's Manual
American Hearth Download Architecture
American Hearth  Rushmore Clean-Face Direct-Vent Liner Kits
Product Warranty
American Hearth Product Warranty
10-year Limited Warranty on Combustion Chamber, Limited Lifetime on Glass. All other parts carry a three-year limited warranty. All remote controls and lighting systems carry a one-year limited warranty.Â
Product FAQs
American Hearth Product FAQs
Can I buy a fireplace online and install it myself?
Does our product work during a power outage?
What is the difference between, Millivolt and electronic ignition fireplaces?
Can I use a Wi-Fi Thermostat with my unit?
Where can I find my model and serial number?
Can you tell me how old my unit is?
Once you locate your rating plate the serial number will help identify the age, the first two digits of the serial number denote the year of manufacture (21, 20, 19...) the next two digits identify the week of that year that the unit was built.
